4.4 ADS Stimuli Box

There is no possibility to connect the ADS Stimuli Box for the QM.

The ADS Stimuli Box is used to stimulate the tank pressure, the pipe pressure and the acceleration. The valve actuator signals trigger the generation of the acceleration stimulus (electrically isolated over opto couplers). You can set the pressures and acceleration with potentiometers. The status of the valves are displayed with LEDs.

Figure 44: Stimuli Box Schematic
\begin{figure}\epsfig{file=stimulibox.epsi, height=220mm} \end{figure}
